Dahua-DH-IPC-EBW81242P-Panoramic Network IR Fisheye Camera


Dahua-DH-IPC-EBW81242P-Panoramic Network IR Fisheye Camera

12MP Panoramic Network IR Fisheye Camera

> 12MP, 1/1.7”CMOS image sensor
> Max output 12MP (4000×3000)@30fps
> 3D DNR,AWB,HLC, BLC,ROI, SVC, SMART H.264/H.265
> People counting in multiple areas, queuing management in multiple areas, heat map (number of peole /time), and track map
> 2/2 Alarm in/out, 1/1 audio in/out
> 12V DC/POE power support
> IP67, IK10 protection

344,984.64

Dahua-DH-IPC-EBW81242P



Dahua-DH-IPC-EBW81242P-

Launched by Dahua Technology, Dahua WizMind is a full portfolio of
solutions composed of project-oriented products including IPC, NVR,
PTZ, XVR, Thermal and software platform which adopts industry-leading
deep learning algorithms. Focusing on customer’s requirements,
WizMind provides precise, reliable and comprehensive AI solutions for
verticals.

MORE FROM TESHOPNG?

DATASHEET



SKU: DH-IPC-EBW81242P Categories: ,
Camera
Image Sensor 1/1.7”12Megapixel progressive CMOS
Max. resolution 4000 (H) × 3000 (V)
ROM 4 GB
RAM 4 GB
Illuminator Number 3 (IR LEDs)
Electronic Shutter Speed 1/3 s-1/100000 s (Auto/Manual)
Min. Illumination 0.01 Lux@F2.0(Color,30IRE)

0.001Lux@F2.0(B/W,30IRE)

0 lux (Illuminator on)

Illumination Distance 10 m (32.8 ft)
Scanning System Progressive
Noise Reduction 3D NR
WDR DWDR
S/N Ratio > 56 dB
Gain control Manual
White Balance Auto/Natural/street lamp/outdoor/manual/regional Custom
Lens
Focal Length 1.85 mm
Mount Type M12
Max. Aperture F2.0
Aperture Type Fixed aperture
Lens Type Fixed focal
Field of View Horizontal: 185°; Vertical: 180°
DORI Distance Detect Observe Recognize Identify
40.0 m (131.3 ft) 16.0 m

(52.6 ft)

8.0 m

(26.3 ft)

4.0 m

(13.1 ft)

Audio
Audio Input 1 channel (RCA port),1 build in MIC
Audio Output 1 channel (RCA port)
Audio Compression G.711A, G.711Mu, G726
Video
Video Compression H.265, H.264, H.264H, H.264B, MJPEG (only supported by the sub stream)
Smart Codec Smart H.265+/ Smart H.264+
Video Bit Rate H264: 88Kbps-16384Kbps ;H265: 52Kbps-16384Kbps
Video Frame Rate 50Hz Main Stream (4000 × 3000@25fps), sub Stream (704 × 576@25fps), third Stream (704 × 576@25fps)

60Hz Stream (4000 × 3000@30fps), sub Stream (704 × 480@30fps), third Stream (704 × 480@30fps)

Fisheye:

1O (4000 x 3000)

1P (4096 x 1024)

2P (2432 x 2432)

1R (1216 x 1216)

2R (2432 x2432)

4R (2432 x 2432)

1O + 3R (2432 x 2432)

Resolution 4000 × 3000, 2880 × 2880, 2880 × 2160, 2048 × 1536 (3M), 1280 × 960 (1.3M), (704 × 576/704 × 480) D1, (352 × 288/352 × 240) CIF
Bit Rate Control CBR/VBR
Region of Interest Yes (4 areas)
Smart Illumination Yes (Adjust by user)
Language English, Italian, Spanish, Russian, French, German, Portuguese, Polish, Korean, Persian, Czech, Dutch, Arabic, European Spanish
Alarm
Alarm Input 2 channels (Wet contact, and it supports max potential 3V-5V)
Alarm Output 2 channels (Dry contact, and it supports max potential 30V)
Function
SD Card Yes
Storage FTP, Micro SD card (256 G)
Max User 20 (Total bandwidth: 240 M)
Browser IE: IE11, IE10, IE9
Google of high version: 48.0.2564.116
Firefox of high version: 48.0.2
Non-plug edge: 42.17134.1.0
Privacy Masking 4 areas
Smart event
IVS Analyze Intrusion, tripwire
Heat Map Yes
Professional, intelligent
People Counting People counting in 4 areas, number of people threshold alarm, 4 queue management, stranding alarm, number of people alarm, number of people heat map, average stranding heat map, track map and export (Report max range is 1 week.)
Network and port
Protocol HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP, NTP
Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Interoperability ONVIF (Profile S/Profile G),CGI
General
Power Supply 12V DC /PoE (802.3af)
Power Consumption Basic power consumption: 6.2W (12V DC), 9.2W (POE)
Max power consumption: (ICR switch, and IR full intensity): 9.2W (12V DC), 12.9W (POE)
Operating Conditions -30°C to +45°C (-22°F to +113°F)/Less than 95% RH
Storage Conditions -30°C to +70°C (-22°F to +158°F)
Protection Grade IP67, IK10
Casing Metal + Plastic
Dimensions 59.8 mm × Φ149.8 mm (2.35” × Φ5.9”)
Net Weight 0.77 kg(1.70 lb)
Gross Weight 1.16 kg(2.56 lb)
Certification CE-LVD:EN62368-1

CE-EMC:Electromagnetic Compatibility Directive 2014/30/EU

FCC:47 CFR FCC Part 15, Subpart B

UL/CUL:UL60950-1 CAN/CSA C22.2 No.60950-1-07
