DAHUA-DH-IPC-HDPW1230R1P-0280B-S5


DAHUA-DH-IPC-HDPW1230R1P-0280B-S5

2MP Entry IR Fixed-Focal Dome Netwok Camera

> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition
> Outputs max. 2MP (1920 × 1080) @25/30 fps
> H.265 codec, high compression rate, ultra-low bit rate
> Built-in efficient IR illuminator, and the max. illumination distance is 30 m
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Abnormality detection: Motion detection, video tampering, network disconnection, IP conflict, illegal access
> 12V DC/PoE power supply
> IP67 protection

25,945.92

DAHUA-DH-IPC-HDPW1230R1P-0280B-S5

Series Overview
With features of simple installation, easy operation, and high
performance-cost ratio, Dahua Entry series network camera is
applicable to small and medium-sized scenes, such as homes/
residences, small-sized retail stores, and other small and medium-sized
enterprises.
Functions
Smart H.265+ & Smart H.264+
With advanced scene-adaptive rate control algorithm, Dahua smart
encoding technology realizes the higher encoding efficiency than H.265
and H.264, provides high-quality video, and reduces the cost of storage
and transmission.

DAHUA-DH-IPC-HDPW1230R1P-0280B-S5
DAHUA-DH-IPC-HDPW1230R1P-0280B-S5

Motion Detection
When moving objects appear in the monitoring image, Dahua Motion
Detection (General) technology triggers alarm or records.
Smart Illumination
Dahua Smart Illumination technology can display image in the
environment of low illuminance or completely dark environment.
According to the distance of the targets, the camera adjusts
Illuminations intensity automatically to display the details of the moving
target.
Smart Codec Motion Detection Smart Illumination
Image Flip
For narrow and long scenes, Dahua image flip technology flips the image
by 90°/180°/270° to realize better surveillance in rotation mode.
Cyber Security
Dahua network camera is equipped with a series of key security
technologies, such as security authentication and authorization, access
control, trusted protection, encrypted transmission, and encrypted
storage, which improve its security defense and data protection, and
prevent malicious programs from invading the device.
Protection (IP67, wide voltage)
IP67: The camera passes a series of strict test on dust and soak. It has
dust-proof function, and the enclosure can works normal after soaking
in 1 m deep water for 30 minutes.
Wide voltage: The camera allows ±30% (for some power supplies)
input voltage tolerance (wide voltage range), and it is widely applied to
outdoor environment with instable voltage.

MORE FROM TECHSHOP

DATASHEET

SKU: DH-IPC-HDPW1230R1P-0280B-S5 Category:
  • Camera
    Image Sensor 1/2.8″ CMOS
    Max. Resolution 1920 (H) × 1080 (V)
    ROM 16 MB
    RAM 64 MB
    Scanning System Progressive
    Electronic Shutter Speed Auto/Manual 1/3 s–1/100000 s
    Min. Illumination 0.01 Lux @F2.0
    S/N Ratio >56 dB
    Illumination Distance 30 m (98.4 ft)
    Illuminator On/Off Control Auto/Manual
    Illuminator Number 1 (IR LED)
    Pan/Tilt/Rotation Range Pan: 0°–355°

    Tilt: 0° –75°

    Rotation: 0°–355°

    Lens
    Lens Type Fixed-focal
    Lens Mount M12
    Focal Length 2.8 mm; 3.6 mm
    Max. Aperture 2.8 mm: F2.0

    3.6 mm: F2.0

    Field of View 2.8 mm: Horizontal: 102°; Vertical: 54°; Diagonal: 120°

    3.6 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100°

    Iris Control Fixed
    Close Focus Distance 2.8 mm: 0.5 m (1.6 ft)

    3.6 mm: 0.8 m (2.6 ft)

    DORI Distance Lens Detect Observe Recognize Identify
    2.8 mm 37.3 m
    (122.4 ft)
    14.9 m

    (48.9 ft)

    7.5 m

    ( 24.6 ft)

    3.7 m
    (12.1 ft)
    3.6 mm 53.3 m

    (174.9 ft)

    21.3 m

    (69.9 ft)

    10.7 m
    (35.1 ft)
    5.3 m
    (17.4 ft)
    Video
    Video Compression H.265; H.264; H.264B; MJPEG (only supported by the sub stream)
    Smart Codec Smart H.265+/Smart H.264+
    Video Frame Rate Main Stream:

    1920 × 1080 (1 fps–25/30 fps)

    Sub stream:

    704 × 576 (1 fps–25 fps)

    704 × 480 (1 fps–30 fps)

    Stream Capability 2 streams
    Resolution 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
    Bit Rate Control CBR/VBR
    Video Bit Rate H.264: 32 kbps–6144 kbps

    H.265: 12 kbps–6400 kbps

    Day/Night Auto (ICR)/Color/B/W
    BLC Yes
    HLC Yes
    WDR DWDR
    White Balance Auto; natural; street lamp; outdoor; manual; regional custom
    Gain Control Auto/Manual
    Noise Reduction 3D NR
    Motion Detection OFF/ON (4 areas, rectangular)
    Region of Interest (RoI) Yes (4 areas)
    Smart Illumination Yes
    Image Rotation 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
    Mirror Yes
    Privacy Masking 4 areas
    Alarm
    Alarm Event Network disconnection; IP conflict; illegal access; motion detection; video tampering; safety exception
    Network
    Network RJ-45 (10/100 Base-T)
    SDK and API Yes
    Cyber Security Video encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
    Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; Multicast
    Interoperability ONVIF (Profile S/Profile T); CGI; P2P; Genetec
    User/Host 6 (Total bandwidth: 36 M)
    Storage FTP
    Browser IE
    Chrome
    Firefox
    Management Software Smart PSS; DSS; DMSS
    Mobile Client IOS; Android
    Certification
    Certifications CE-LVD: EN62368-1

    CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

    FCC: 47 CFR FCC Part 15, Subpart B

    Power
    Power Supply 12V DC/PoE (802.3af)
    Power Consumption Basic power consumption: 1.6W (12V DC); 2.4W (PoE)

    Max. power consumption (ICR + H.265 + IR intensity): 3.9W (12V DC); 4.7W (PoE)

    Environment
    Operating Conditions -40°C to +60°C (-40°F to +140°F)/less than ≤ 95%
    Storage Temperature -40°C to +60°C (-40°F to +140°F)
    Protection IP67
    Structure
    Casing Plastic
    Product Dimensions 98.1 mm × Φ122 mm (3.9″ × Φ4.8″)
    Net Weight 0.34 kg (0.7 lb)
    Gross Weight 0.52 kg (1.1 lb)
