Uniview CAB-LC3100B-E-IN Cat6 UTP- 305m-Orange-UNV
₦193,200.00
Uniview CAB-LC3100B-E-IN Cat6 UTP- 305m-Orange-UNV
Product model: CAB-LC3100B-E-IN
Product specification: HSYV-6 4×2×0.57
Test Standard: YD/T1019-2013
CAT.6 Orange Cable without UL
| Product Model | CAB-LC3100B-E-IN |
| Product Specification | HSYV-6 4×2×0.57 |
| Test Standard | YD/T1019-2013 |
| Conductor | Material: OFC(Oxygen free copper) AWG: 23 Nom.O.D.(mm): 0.57±0.005 mm DC resistance: ≤95 Ω/km |
| Insulation | Material: HDPE Thickness: 0.2±0.02 mm Diameter: 1.02±0.05 mm |
| Pitch | Offset pitch: ≤20 mm Cable pitch: ≤120 mm |
| Sheath | Material: PVC (complies with RoHS/REAC) External O.D.: 6.2±0.3 mm Color: Blue (RAL5015) Tensile strength: >13.5 Mpa Thickness: 0.6±0.05 mm |
| Surface Printing | Letter height: 3.0±0.3 mm Color: Black Print error & Space: 1±0.005 m Case number: Yes |
| Packing | Packing: Carton Once packing dimensions: 420mm*205mm*420mm Twice packing dimension: 450mm*440mm*445mm Twice packing quantity: 2 cases |
| Packing Length | 305±1m |
| Rip-Cord | Yes |
| Crossing Backbone | Yes |
| Ambient Temperature | -20℃～60℃ |
| Brand |
Uniview |
|---|---|
| Solutions |
Datacom & Storage |
